Separett Villa Separating Toilet 67.2 X 46.6 X 54.1 Cm 12/230 V

With its simplicity and unlimited capacity, this separation toilet offers you a worry-free toilet experience. With the 2020 renewed 12V fan, the toilet installation can handle a distance up to 6 m in length and three 90° bends.

Quiet and odorless
Separett Villa 9010 is a separation toilet, which with its simplicity and unlimited capacity offers comfortable toilet use. Thanks to the urine separation, both the odor and the volume of waste are reduced. With the 12V fan renewed in 2020, the installation can handle a distance up to 6 m long and three 90° bends.

The toilet can be operated with 230 V mains power or 12 V solar cells/battery power. The fan (2.5 W, 210 mA) has a low energy consumption and is therefore ideally suited for battery/solar cell operation. With battery operation (12 V, 100 Ah), the service life is approximately 2 weeks. The battery is not included in the delivery.

High capacity
Due to the high capacity, the toilet works equally well in continuous and alternating operation. Therefore, it is ideal for both leisure and permanent operation in the house. In a vacation home with 5 people, the tank of the toilet must be emptied approximately every 4 to 6 weeks.

High reliability
The Villa 9010 has high operational reliability, is easy to install and takes up as much space as a conventional toilet seat. The environment is constantly ventilated by the fan and urine is separated from the rest of the business, keeping the toilet environment free of odors. The privacy screen hides solid waste and automatically slides open when you sit down to go to the toilet.

How it works
Separett Villa is a separation toilet that separates urine from solid excreta and is equipped with a ventilator that removes moisture and air, providing an odor-free environment during toileting. Urine is drained into an external collection container or sent to infiltration, while solid excreta products end up in a compostable organic bag made of corn starch.

Installation
Separett Villa has no requirements for room temperature and therefore works equally well in cold and warm rooms. The only requirements are that the urine can be drained and a ventilation pipe can be installed. For Villa 9010 we recommend using a maximum of two 90° bends and 4 m of pipes.

Details:

• Filter by function Battery/solar operation
• Capacity Unlimited – need for emptying depends on the amoynt of users
• Product weight: 19 kg
• Packing weight: 21 kg
• Max. User weight: 150 kg
• Product dimensions: 67,2 x 45,6 x 54,1 cm
• Seat height 44 cm
• Package size: 77 x 47 x 66 cm
• Material: Recyclable high gloss polypropylene
• Emptying interval for 4 users: (urine) When the eventual container is full
• Emptying interval for 4 users: (solids) Every 4-6 weeks
• Energy consumption: 0.06 kWh / 24h
• Connection: Battery cable 1.9 m or mains adapter 12 V / 230 V
• Total power: 12 V/2.5 W/210 mA
• Voltage: 12V
• Ventilation duct/pipe Ventilation pipe Ø75 mm | urine outlet pipe Ø32 mm
• Noise level during operation <30 dB(A)

Scope of delivery

• Villa 9010 waterless separation toilet, 12 V / 230 V
• Operating and installation instructions
• Universal adapter for power socket
• Battery cable for solar/battery use
• Three waste containers incl. two lids
• 10 x compostable waste bags
• Straight connector suitable for 90° connection
• 90° connection for the Ø 75 mm ventilation pipe
• Ventilation pipe 40 cm Ø 75 mm for easy installation through the wall
• Rain cover for vertical installation of the ventilation pipe
• Ventilation grille for horizontal installation of the ventilation pipe
• Insect net for the ventilation pipe
• Internal surround for the Ø 75 mm ventilation pipe and Ø 32 mm urine hose
• 2 m white urine hose Ø 32 mm to drain the urine
• 90° connection for the Ø 32 mm urine hose
• Straight connector for the Ø 32 mm urine tube
• Silicone strip to seal the bottom of the toilet
• Wall bracket for fixing the toilet in the wall
• 2 x wall bracket for fixing the urine hose
• Screws for fixing the toilet in the wall or in the floor
• Probe Bio drain cleaner tablets – to prevent blockages inside the urine hose
• Probe Absorb – absorbent cloth to prevent excessive moisture in the waste container
• Installation template
