SOG Type F Additional Connection

12 V venting – the clean, odorless solution!

A specially developed small high-performance fan, which switches on automatically when the toilet slide is opened, creates a negative pressure in the waste-holding tank:

This creates a “suction” at the slider opening that draws in fresh air, as well as odors created during use, and directs it outside. The drawing in of air acts as a seal and 100% prevents all unpleasant foul gases from rising from the tank. Thus, with each use, more air (oxygen) is drawn into the cassette. Water is also supplied each time through the flushing process. However, after the slider is automatically switched off and closed, there is permanent ventilation – i.e. oxygen supply – through a pipe or hose connection that is always open to the outside, thus promoting the further decomposition process.

SOG I-door variant:

The fan is mounted directly on the inside of the disposal door. On the outside, the housing with activated carbon filter is attached (can be painted in car color).

Scope of delivery:

Fan, adapter parts, cable set with switch for power supply to the fan, complete small parts for installation, installation instructions, filter housing, carbon filter mat.

Type A:	Thetford C2/3/4
Type B:	Thetford C200
Type C:	Thetford Porta Potti & Dometic Transportable
Type D:	Thetford C400
Type F:	Thetford C250/260
Type G:	Thetford C500
Type H:	Thetford C220
Type 3000A:	Dometic CT3000/4000
