WM Aquatec Biolite UV-C LED Drinking Water Disinfection Unit

WATER DISINFECTION WITH UV-LEDS – WATER DISINFECTION WITH
UV-LEDSThanks to innovative UV-C LED technology, the
biolite UV disinfection devices from WM aquatec have an extraordinarily high disinfection performance in a very compact design. In contrast to previous UV technology, no environmentally hazardous mercury-containing gas discharge lamps are used here, but the latest UV-C LED technology, which offers enormous advantages

MAINTENANCE-FREE
LEDs do not have a start or warm-up phase, they are only switched on at the same time as the water is drawn off, resulting not only in very low power consumption but also in a long service life of several years – without the need to replace lamps.
Therefore biolite disinfection devices are virtually maintenance-free

CHEMIEFREIDThe
water to be disinfected is irradiated with short-wave UV light.
The genetic information of the pathogens contained in the DNA adsorbs the energy of the UV-C radiation and is destroyed. This purely physical process enables efficient disinfection of the water (up to 99.999%), without the use of chemical disinfectants.

ULTRACOMPACT
With a flow rate of up to 8l/min they are perfectly suited for the disinfection of drinking water in e.g. motor homes, expedition vehicles, food trucks or yachts. In addition, the LED light sources, the ballast and the control unit are housed in a high-quality stainless steel housing, which is a plug & play solution with intelligent connections on the electrical and water sides.

FUNCTIONAL WATER DISINFACTION
by means of UV-C radiation is a water treatment technology that has been successfully used for decades and is used in public drinking water supply, medical areas and industry, among others.
The water to be disinfected is irradiated with short-wave UV light. The genetic information of the microorganisms contained in the DNA adsorbs the energy of the UV-C radiation and is destroyed. Viruses and bacteria can be effectively inactivated by UV-C radiation and prevented from multiplying. This purely physical process enables a disinfection of the water up to 99.999%, without the use of chemical disinfectants

• Water disinfection – 100% without chemicals
• newest, innovative UV-C LED technology
• Disinfection performance up to 99,999%
• up to 8 l/min flow rate – parallel connection possible for higher flow rates
• suitable for submersible and pressure pumps
• environmentally friendly: mercury-free and without harmful disinfection by-products
• low power consumption due to real-timeBetrieb≥ disinfection directly at water withdrawal (real-time operation)
• easy to retrofit in existing fresh water systems
• can be used for over 13 years* with unlimited switching cycles
• no lamp replacement nötig≥ maintenance-free (with annual fresh water system cleaning)
• safe operation through integrated current or function monitoring, temperature monitoring, service life monitoring and signalling (optical & acoustic) incl. connection
  material (electrical & water side)

*with an average water withdrawal of 365 hours per year
